| Quantity: | |
|---|---|
Series | Stock No Color | Type I, II, III, and IV | Two-leg or Single Basket | type V | ||||||
| Single-leg | Horizontal Angle | |||||||||
| Hitch Type Width ,in. | Vertical | choke | vertical basket | vertical basket | 60 deg | 45 deg | 30 deg | Endless Vertical | ||
Width ,in. | ||||||||||
Class 5 | EE5501 | 1 | 2200 | 1760 | 4400 | 4400 | 3800 | 3100 | 2200 | 4400 |
| EE5501.5 | 1 1/2 | 3300 | 2640 | 6600 | 6600 | 5700 | 4700 | 3300 | 6600 | |
| EE5501.75 | 1 3/4 | 3800 | 3040 | 7600 | 7600 | 6600 | 5400 | 3800 | 7600 | |
| EE5502 | 2 | 4400 | 3520 | 8800 | 8800 | 7600 | 6200 | 4400 | 8800 | |
| EE5503 | 3 | 6600 | 5280 | 13200 | 13200 | 11400 | 9300 | 6600 | 13200 | |
| EE5504 | 4 | 8200 | 6560 | 16400 | 16400 | 14200 | 11600 | 8200 | 16400 | |
| EE5505 | 5 | 10200 | 8160 | 20400 | 20400 | 17700 | 14400 | 10200 | 20400 | |
| EE5506 | 6 | 12300 | 9840 | 24600 | 24600 | 21300 | 17400 | 12300 | 24600 | |
Class 7 | EE7501 | 1 | 3100 | 2480 | 6200 | 6200 | 5400 | 4400 | 3100 | 6200 |
| EE7501.5 | 1 1/2 | 4700 | 3760 | 9400 | 9400 | 8100 | 6600 | 4700 | 9400 | |
| EE7501.75 | 1 3/4 | 5400 | 4320 | 10800 | 10800 | 9400 | 7600 | 5400 | 10800 | |
| EE7502 | 2 | 6200 | 4960 | 12400 | 12400 | 10700 | 8800 | 6200 | 12400 | |
| EE7503 | 3 | 8800 | 7040 | 17600 | 17600 | 15200 | 12400 | 8800 | 17600 | |
| EE7504 | 4 | 11000 | 8800 | 22000 | 22000 | 19100 | 15600 | 11000 | 22000 | |
| EE7505 | 5 | 13700 | 10960 | 27400 | 27400 | 23700 | 19400 | 13700 | 27400 | |
| EE7506 | 6 | 16500 | 13200 | 33000 | 33000 | 28600 | 23000 | 16500 | 33000 | |
| EE7508 | 8 | 22750 | 18200 | 42350 | 42350 | 36700 | 29900 | 22750 | 42350 | |
| EE7510 | 10 | 28400 | 22720 | 52900 | 52900 | 45800 | 37400 | 28400 | 52900 | |
| EE7512 | 12 | 34100 | 27280 | 63500 | 63500 | 55000 | 44900 | 34100 | 63500 | |
Series | Stock No Color | Type I, II, III, and IV | Two-leg or Single Basket | type V | ||||||
| Single-leg | Horizontal Angle | |||||||||
| Hitch Type Width ,in. | Vertical | choke | vertical basket | vertical basket | 60 deg | 45 deg | 30 deg | Endless Vertical | ||
Width ,in. | ||||||||||
Class 5 | EE5501 | 1 | 2200 | 1760 | 4400 | 4400 | 3800 | 3100 | 2200 | 4400 |
| EE5501.5 | 1 1/2 | 3300 | 2640 | 6600 | 6600 | 5700 | 4700 | 3300 | 6600 | |
| EE5501.75 | 1 3/4 | 3800 | 3040 | 7600 | 7600 | 6600 | 5400 | 3800 | 7600 | |
| EE5502 | 2 | 4400 | 3520 | 8800 | 8800 | 7600 | 6200 | 4400 | 8800 | |
| EE5503 | 3 | 6600 | 5280 | 13200 | 13200 | 11400 | 9300 | 6600 | 13200 | |
| EE5504 | 4 | 8200 | 6560 | 16400 | 16400 | 14200 | 11600 | 8200 | 16400 | |
| EE5505 | 5 | 10200 | 8160 | 20400 | 20400 | 17700 | 14400 | 10200 | 20400 | |
| EE5506 | 6 | 12300 | 9840 | 24600 | 24600 | 21300 | 17400 | 12300 | 24600 | |
Class 7 | EE7501 | 1 | 3100 | 2480 | 6200 | 6200 | 5400 | 4400 | 3100 | 6200 |
| EE7501.5 | 1 1/2 | 4700 | 3760 | 9400 | 9400 | 8100 | 6600 | 4700 | 9400 | |
| EE7501.75 | 1 3/4 | 5400 | 4320 | 10800 | 10800 | 9400 | 7600 | 5400 | 10800 | |
| EE7502 | 2 | 6200 | 4960 | 12400 | 12400 | 10700 | 8800 | 6200 | 12400 | |
| EE7503 | 3 | 8800 | 7040 | 17600 | 17600 | 15200 | 12400 | 8800 | 17600 | |
| EE7504 | 4 | 11000 | 8800 | 22000 | 22000 | 19100 | 15600 | 11000 | 22000 | |
| EE7505 | 5 | 13700 | 10960 | 27400 | 27400 | 23700 | 19400 | 13700 | 27400 | |
| EE7506 | 6 | 16500 | 13200 | 33000 | 33000 | 28600 | 23000 | 16500 | 33000 | |
| EE7508 | 8 | 22750 | 18200 | 42350 | 42350 | 36700 | 29900 | 22750 | 42350 | |
| EE7510 | 10 | 28400 | 22720 | 52900 | 52900 | 45800 | 37400 | 28400 | 52900 | |
| EE7512 | 12 | 34100 | 27280 | 63500 | 63500 | 55000 | 44900 | 34100 | 63500 | |
